WUXI JINHAIHUA TECHNOLOGY CO.,LTD Prevent & Protect
6 Years
| Ask Lasest Price | |
| Brand Name : | DESEO |
| Model Number : | SD4600 |
| Certification : | CE/ISO9001:2008 |
| Price : | USD 800/UNIT |
| Payment Terms : | T/T |
| Supply Ability : | 200 unit per month |
| Delivery Time : | 7-20 days |
Feature:
- Copper Color, NEW & ELEGANT LOOK.
- Door panel fingr protection patent designed. Saftey use.
- Design with the Small Window & small door is available.
- Easy installation. Our doors has pre-installed & tested in our factory.
- Self-locking while the power off. Saves our worry on the safety even when the power get cut off.
- Quality guaranteed. Our industrial door workshop & products are CE certificated.
Technical Data:
| Material options | 1. 304 STAINLESS STEEL 0.38mm-0.48mm 2. Aluminum material door panel with polyethene foam filled 3. Galvanized steel plate, with any ral color |
| Door panel height | 450mm & 550mm |
| Normal Color | Porcelain white, light gray,coffee color and stainless steel color, or any Ral color. |
| Rail & Fitting | Hot dip galvanized steel rail and galvanized bracket & hinges. Aluminum powder coated 2.8mm thick rail is also optional. |
| Sealing | With full sealed, weather resistance & well protection & soundproof. |
| Control | Automatic & remote controlled. Power rate: 220V/380V |
| Feature for door motorized system | Route memorable, door self locking when power cut off, self-checking up, non hand nipping, safety operation. |
| Certification | ISO & CE certificated. |
No. of revolutions: 24 rpm
Protection class: IP 54
Limit Switch: Electronical
Door opening speed: 0.20 meter/second
Filling: Polyurethene PUR 25-60-25-100% HFCKW free
Heat Transfer Coefficient1 (U): 1.0 W/m2K
Heat resistance of the panel: 1.484 m2 K/W
R Value; 1.66
K Value of the panel: 0.604 W/m2K
Sound insulation value of the panel: 26DB
|
|
